Our Fluid Bed Dryers comprise of a simple drying unit which precisely converts the product to granulation or coater when optional packages are engulfed. Our dryers are available in Standard Pneumatic Logic and a Sophisticated Computerized control which is offered in Steam Heated Models. Fluid Bed Dryer is the best solution for drying products as it is a high performance machine as compared to conventional drying methods which are not sufficient and troublesome.

Fluid Bed Dryer Manufacturer supplier exporter in India
Fluid Bed Dryer Manufacturer in India

Key Features

  • Provides complete control over the condition of the processing air.
  •  Delivers uniform drying in a short duration of time with low labor input.
  • The 20 micron single/multi-stage filter at the atmospheric air inlet restricts the entry of any dust or impurities.
  • A digital temperature indicator displays the inlet and outlet temperature readings and also allows to control the temperature.
  •  The steel coil which is made out of 1″ dia.SS 304/316 fine tube is especially designed to produce pressure of 3-4kg./cm^2. [Working pressure 3 kg/cm^2]
  •  The machine is equipped with suction and discharge dampers to control the inlet and outlet of air.
  • An explosion safety flap comes at the rear end of the dryer along with a positive earthling point timer which cuts-off the motor supply at the set process completion time.

Specification

DESCRIPTIONFBD-10FBD-30FBD-60FBD-120FBD-200FBD-250
Capacity Of Dryer In Kgs At 0.6 Kg/lt Bulk Density10-2530-5050-70120-150200-220250-270
Working Capacity Of Product Container In Liters1050100200335420
Total Volume Of Product Container In Ltrs20100200400580760
Blower Motor HP2 H.P.5 H.P.10 H.P.15 H.P.20 H.P.20 H.P
Heater Load9 K.W.18 K.W.36 K.W.60 K.W.
Steam Consumption15 KGS25 KGS55 KGS110 KGS180 KGS240 KGS
Heating Capacity In Kcl/hr84101161023220387007740096750
SPACE REQUIREMENTS APPROX.
Length125015501550248025002700
Width6009001200140021501900
Height With Motor125021502650295034003500
